Without measurement there is no control.
BENEFITS
• ISO 21501-4 compliant with a built-in Pulse
Height Analyzer (PHA)
• 100 LPM, 50 LPM, or 1 CFM flow rates
available
– 100 LPM flow samples 1 m
3
in 10 minutes
• Large IR touchscreen for simplified use
• Quiet pump improves work environment
• Calculates and creates reports for ISO
14644-1, EC GMP Annex 1, China GMP, and
FS 209E
• 21 CFR Part 11 compliant download
• Comprehensive validation manual makes
it easy to meet pharmaceutical regulatory
requirements
• Operates in cleanrooms via a web browser:
Set up, sample, display, print, download
data
• Choose from ten languages for display and
printout
• Removable batteries with optional external
charger for continuous mobile use
• Stores sampling recipes to reduce operator
errors
• Long-term data archiving with DataAnalyst
software
• Local printout for immediate hardcopy
results
• USB electronic printouts for long term
storage
• CSV file download for easy data integration
• Web browser for simplified remote
operation
APPLICATIONS
• Cleanroom monitoring
• Facility certification for ISO, EC GMP, China
GMP, FS 209E
• Trend analysis
• Statistical process control
• Troubleshooting particle excursions
• Manifold compatible
• Portable or dedicated use
The Lasair III Particle Counter sets the standard for portable aerosol particle
counters and meets the requirements of ISO 21501-4.
The Lasair III Particle Counter is available in three different flow rate
configurations (1 CFM, 50 LPM and 100 LPM) to meet a variety of cleanroom
applications. It can be used for routine fixed and portable cleanroom
monitoring. Interactive software steps the user through the ISO 14644-1,
EC GMP Annex 1, China GMP, and FS 209E room certification process.
The results of cleanroom certifications are available either through a local
printout, downloadable via USB in a secure format, or through the use of
external software packages such as DataAnalyst, Facility Net software or
Pharmaceutical Net software.
The user interface is facilitated by the use of a large easy-to-read IR
touchscreen. The touchscreen eliminates interaction problems commonly
associated with resistive or capacitive touchscreens such as requiring the use
of a stylus or difficulties using a touchscreen while wearing gloves.
The rugged chemical-resistant enclosure is lightweight for portability and
has a streamlined design to minimize particle traps, making the unit easy
to clean. Power is provided to the unit through the use of the on-board
hot-swappable batteries. Power can also be provided through the use of an
external AC power source, which can simultaneously power the unit as well Pdf manual sony cfs-3000 user.
as charge the on-board batteries.
The Lasair III Particle Counter can accept inputs from a wide range of
environmental sensors through the four built-in 4-20 mA inputs. Wireless
network communications is made easy with an externally-mounted wireless
adapter, simplifying communications with network systems. The unit can
be remotely managed via the built-in web browser function or through
Ethernet to Pharmaceutical Net , Facility Net, or FacilityPro™ software.
Lasair® III
Aerosol Particle Counter Models 310B, 310C, 350L, 5100
© 2012 Particle Measuring Systems, Inc. All rights reserved.
AUTHORIZED REPRESENTATIVE
specifications
081612
Particle Measuring Systems Headquarters
5475 Airport Blvd., Boulder, CO 80301, USA
Tel: +1 303 443-7100 +1-800-238-1801
FAX: +1 303 449-6870
Instrument Service & Support: +1 800-557-6363
Customer Response Center: +1 877-475-3317
PMS EMEA
Tel: +44 1684 581 000
Email: PMSEMEA@pmeasuring.com
Particle Measuring Systems France
Tel: +33 160 10 32 96
Email: PMSFrance@pmeasuring.com
Particle Measuring Systems Germany
Tel: +49 2222 9299 522
Email: PMSGermany@pmeasuring.com
Particle Measuring Systems Italia
Tel: +39 06 9053 0130
Email: PMSSRL@pmeasuring.com
Particle Measuring Systems Nordic
Tel: +45 707 028 55
Email: PMSNordic@pmeasuring.com
Particle Measuring Systems China
Tel: +86 21 6113 3600
Email: pmschina@pmeasuring.com
Particle Measuring Systems Japan
Tel: +81 3 5298 8175
Email: PMSJapan@pmeasuring.com
Particle Measuring Systems Singapore
Tel: +65 6496 0330
Email: PMSSingapore@pmeasuring.com
Particle Measuring Systems Brazil
Tel: +55 11 5188 8166
Email: PMSBrazil@pmeasuring.com
Particle Measuring Systems Mexico
Tel: +52 55 2271 5106
Email: PMSMexico@pmeasuring.com
Particle Measuring Systems Puerto Rico
Tel: +1 787 718 9096
Email: PMSPuertoRico@pmeasuring.com
310B, 310C
350L
5100
Channels
310B: 0.3, 0.5, 1.0, 3.0, 5.0, 10.0 µm
310C: 0.3, 0.5, 1.0, 5.0, 10.0, 25.0 µm
0.3, 0.5, 1.0, 5.0, 10.0, 25.0 µm 0.5, 1.0, 2.0, 5.0, 10.0, 25.0 µm
Flow rate
1.0 CFM (28.3 LPM) ± 5%
50 LPM ± 5%
100 LPM ± 5%
Calibration
Meets ISO 21501-4 requirements
Maximum concentration
a
> 1,380,270/ft
3
> 832,599/ft
3
> 688, 495/ft
3
Counting efficiency
50% ± 20% for most sensitive threshold. Meets ISO 21501-4 requirements.
Zero count
7.07 counts/m
3
(1CFM); 4.00 counts/m
3
(50 LPM); 2.00 counts/m
3
(100 LPM)
Data storage
3,000 complete data sets. 21 CFR 11 compliance. Long-term data storage/analysis with DataAnalyst.
Communication modes
Ethernet or RS-232; USB data downloading; optional wireless Ethernet
Controlling software
Facility Net, Pharmaceutical Net, FacilityPro, Microsoft® Internet Explorer® 5.0+, Firefox®
Remote operation
Remote web browser operation; real-time download to Facility Net or Pharmaceutical Net
Reports
USB reports; sample printouts; cleanroom certification reports for ISO, EC GMP, and FS 209E; averaging
Environmental sensors
Four 4-20 mA inputs
Languages
English, French, German, Italian, Japanese (Kanji), Korean, Mandarin Chinese (Traditional or
Simplified), Spanish, Russian
Display and printer
8.4” color VGA display (640 x 480); IR touch screen (IP65 rated); built-in thermal printer
External surface
Lasair Ii Particle Counter Manual
Polycarbonate (PC)
Enclosure cleaning materials Bleach, ethyl/isopropyl alcohol, peroxide/quaternary ammonium solutions
Sample tubing ID
b
3/8”, 8 m max. length
1/2”, 8 m max. length
3/4”, 8 m max. length
Sample output filtering
Internally filtered to > 99.97% at 0.3 µm
Lasair Manual
Power and battery
c
100 – 264 V, 50 – 60 Hz, 150 W
Lithium battery: estimated operation 3 hr (single) 6 hr (dual) for 1 CFM unit
【What you get】 1 x sa-708gt gaming headset, 1 x 3.5mm jack cable 1 to 2 and 1 x user Manual.
Dimensions (h, w, d)
11.9 x 12.9 x 10.2 in (30.1 x 32.7 x 25.9 cm)
Weight
13.2 lb (6 kg) without battery, 16.5 lb (7.5 kg) with two optional batteries
Operating environment
Temperature: 32 – 86 °F (0 – 30 °C); Humidity: 5 – 95% RH non-condensing
All dimensions, weights and values not provided with a tolerance are +/-10% values.
a. Less than 10.0% coincidence loss at maximum recommended concentration.
b. For pharmaceutical applications, tubing length should equal 2m maximum.
Lasair Iii 310c
c. Battery life is based on continuous operation running one (1) minute samples and printing every minute.
Lasair® is a registered trademark of Particle Measuring Systems, Inc.
FacilityPro™ is a trademark of Particle Measuring Systems, Inc.
All other trademarks are the property of their respective owners.
U.S. and foreign patents pending.
Particle Measuring Systems, Inc. reserves the right to change specifications without notice.
