High-resolution, full HD PTZ camera with 1080p25/30 (2MP) resolution and 20x zoom Intelligent Tracking and alarm rules engine with on-board Intelligent Video Analytics (IVA) Enhanced system flexibility with dual recording options (iSCSI, SD card) and dual power source options (High Power over Ethernet (High PoE) / 24 VAC) Fully configurable. The AUTODOME IP dynamic 7000 HD is an easy to install, high-speed PTZ dome camera, in a field-proven outdoor pendant housing, that delivers unmatched picture quality and network performance day and night with superb high definition (HD) 1080p25/30 video and 30x optical zoom.The camera provides complete network-based control of all dome functionality including.
We will relaunch the website to offer you an improved user experience. Please keep in mind to update your bookmark after go-live.
- Configurable streams, based on Bosch’s Common u Easy and intuitive installation with multiple preconfigured user modes that allow users to select the camera configuration that is ideal for their applications The AUTODOME IP dynamic 7000 HD is an easy to install, high-speed PTZ dome camera, in a field-proven.
- MIC IP dynamic 7000 HD. Exceptional strength and ruggedness for any outdoor, industrial, or commercial surveillance application; High Dynamic Range (HDR) to see details in bright and dark areas simultaneously. Bosch OSRD, Pelco P/D, and Forward Vision (Requires connection to a Bosch decoder and camera firmware 6.1 or later).
- Aktuelle SeiteCatalog
- IP Cameras
Our technical support ensure that you can get the best performance from your system.
more..TrainingThe Bosch Security Academy offers classroom training sessions as well as online tutorials.
Learn moreVideo ChannelWatch tutorials, how-to's, and other videos produced for your convenience.
Browse the videosBecome a partnerAs a Bosch Integration Partner, you profit from access to an increasing number of services.
Learn more- Exceptional strength and ruggedness for any outdoor, industrial, or commercial surveillance application
- High Dynamic Range (HDR) to see details in bright and dark areas simultaneously
- Optional, field-installable combo illuminator (IR/White light) provides detection of objects up to 175 m (575 ft) away
- Simple installation with new hinged DCA mounting accessory and new cable design
- ONVIF conformant; provides interoperability with other conformant systems.
- Details
Imager 1/2.8-type Exmor CMOS sensor Effective Picture Elements (Pixels) 1944 x 1224 (2.38 MP) Lens 30x Zoom4.3 mm to 129 mmF1.6 to F4.7 Field of View (FOV) 2.3° to 65° Focus Automatic with manual override Iris Automatic with manual override Digital Zoom 12x Sensitivity / Minimum Illumination (typical) 30 IRE , 50 IRE Day Mode (Color) Fixed shutter 1/30, High Sensitivity mode On 0.052 lux , 0.166 lux Fixed shutter 1/30, High Sensitivity mode Off 0.26 lux , 0.66 lux SensUp On (max. ¼), High Sensitivity mode On 0.0082 lux , 0.033 lux Night Mode (Black and white) Fixed shutter 1/30, High Sensitivity mode On 0.0103 lux , 0.041 lux Fixed shutter 1/4, High Sensitivity mode On 0.00129 lux , --- SensUp On (max. ¼), High Sensitivity mode On 0.00065 lux , 0.00205 lux Gain Control Auto/Manual/Max Aperture Correction Horizontal and vertical Electronic Shutter Speed (AES) 1/1 sec to 1/10000 sec (22 steps) Dynamic Range 90 dB typical Signal-to-Noise Ratio (SNR) >50 dB Backlight Compensation (BLC) On/Off White Balance 2000 K to 10,000 K ATW, AWB Hold, Extended ATW, Manual, Sodium Lamp Auto, Sodium Lamp Day/Night Monochrome, Color, Auto Defog mode feature Improves visibility when viewing foggy or other low-contrast scenes. Drive Unit Brushless, integral pan/tilt motor drive Pan Range 360° continuous rotation Tilt Angle Without illuminators (camera upright): 290°Without illuminators (camera inverted): 250°With illuminators: 186.6° Tilt Range Upright unit: -55° - +90°Canted unit: -90° - +90° Variable Pan Speed 0.2°/second - 120°/second Variable Tilt Speed 0.2°/second - 60°/second Pre-position Speed 120°/second Preset Accuracy 0.17° (typical) Proportional Pan / Tilt to Zoom Yes Zoom Movement Speed <5 seconds (optical Wide to optical TELE) <7.5 seconds (optical Wide to digital TELE) Audible Noise <65dB Input Voltage 21-30 VAC, 50/60 Hzand/orEthernet High PoE cable connection (56 VDC) Power Consumption Without illuminator: 40 W maximumWith illuminator: 70 W maximum Camera Setup/Control Via Internet Explorer web browser version 7.0 or later, Bosch Configuration Manager, Bosch Video Management System (BVMS), Bosch Video Client (BVC), or support for third party software Software Update Network firmware upload Serial protocols Bosch OSRD, Pelco P/D, and Forward Vision (Requires connection to a Bosch decoder and camera firmware 6.1 or later) Standards / Video compression H.264 (ISO/IEC 14496‑10), M‑JPEG, JPEG Streaming Four (4) streams with individually configurable frame rate and resolution: Two (2) independently configurable H.264 recording streams Two (2) non-recording streams (profiles) Stream 1 (recording) Options are:- H.264 MP SD- H.264 MP 720p25/30 Fixed- H.264 MP 1080p25/30 Fixed;- H.264 MP 720p50/60 Fixed Stream 2 Options vary depending on Stream 1 selection. Options with “H.264 MP 1080p25/30 Fixed” selected for Stream 1:Copy Stream 1 H.264 MP SD H.264 MP 720p8/10 Fixed H.264 MP 1080p4/5 Fixed H.264 MP upright (cropped) H.264 MP D1 4:3 (cropped) H.264 MP 1.3 MP 5:4 (cropped) Options with “H.264 MP 720p50/60 Fixed” selected for Stream 1:Copy Stream 1 H.264 MP SD H.264 MP 720p6/7 Fixed H.264 MP upright (cropped) H.264 MP D1 4:3 (cropped) Options with “H.264 MP 720p25/30 Fixed” selected for Stream 1:H.264 MP SD H.264 MP 720p25/30 Fixed H.264 MP upright (cropped) H.264 MP D1 4:3 (cropped) H.264 MP 1280x960 (cropped) Option with “H.264 MP SD” selected for Stream 1: H.264 MP SD Non-recording profiles Two (2) streams, I-frame only Options are:- HD Image Optimized;- HD Balanced;- HD Bit Rate Optimized;- SD Image Optimized;- SD Balanced;- SD Bit Rate Optimized;- DSL Optimized;- 3G Optimized Resolution (H x V) 1080p HD 1920 x 1080 720p HD 1280 x 720 432p SD 768 x 432 288p SD 512 x 288 144p SD 256 x 144 Protocols IPv4, IPv6, UDP, TCP, HTTP, HTTPS, RTP/RTCP, IGMP V2/V3, ICMP, ICMPv6, RTSP, FTP, Telnet, ARP, DHCP, APIPA (Auto-IP, link local address), NTP (SNTP), SNMP (V1, MIB-II), 802.1x, DNS, DNSv6, DDNS (DynDNS.org, selfHOST.de, no-ip.com), SMTP, iSCSI, UPnP (SSDP), DiffServ (QoS), LLDP, SOAP, Dropbox, CHAP, digest authentication Ethernet 10BASE-T/100BASE-TX, auto-sensing, half/full duplex Encryption TLS 1.0, SSL, DES, 3DES, AES Ethernet connector RJ45 Connectivity ONVIF Profile S, Auto-MDIX GOP Structure IP, IBP, IBBP Data Rate 9.6 kbps to 6 Mbps Overall IP Delay 240 ms (typical) Sectors / Titling 16 independent sectors with 20 characters per title Privacy Masking 24 individually configurable privacy masks Virtual Masking 24 individually configurable masks to hide parts of the scene (background motion such as moving trees, pulsating lights, busy roads, etc.) which should not be considered for flow analysis to trigger Intelligent Tracking. Pre-positions 256, each with 20 characters per title Guard Tours Two (2) types of tours: Recorded tours - two (2), maximum total duration 30 minutes (depending on amount of commands sent during recording) Preset tour - one (1), consisting of up to 256 scenes consecutively, and (1) customized up to 64 scenes Supported Languages English, Czech*, Dutch, French, German, Italian, Polish, Portuguese, Russian*, Spanish * Available with separate language upload Power, Network Without illuminator: RJ45 100BASE-TX Ethernet High PoE midspan - 60 W (NPD-6001A) or 95 W (NPD-9501A) With illuminator: High PoE 95 W midspan (NPD-9501A)* Power, Camera 24 VAC (power supply) Video and Control RJ45 100BASE-TX Ethernet RS-485 Simplex 9600 baud (dedicated for MIC-ALM-WAS-24) Alarm/Washer 3-wire RS-485 * Must purchase either NPD-9501A or VIDEOJET connect 7000 in order to use the High PoE solution. Ingress Protection Rating/ Standard IP68NEMA 6P, when using installed MIC-DCA or MIC wall mount IP67 (moisture and dust) rating on connectors in the base of the camera External Mechanical Impact (IK Code or Impact rating) IK10 Operating Temperature -40 °C to +60 °C (-40 °F to +140 °F) NEMA TS 2-2003 (R2008), para 2.1.5.1 using fig. 2.1 test profile -34 ºC to +74 ºC (-30 ºF to +165 ºF) Storage Temperature -60 °C to +70 °C (-76 °F to +158 °F) Humidity 0-100% Wind Load 209 km/h (130 mph) (sustained)(Gusts up to 290 km/h (180 mph)) Effective Projected Area (EPA): 0.044m² (0.47 ft²) Vibration IEC 60068-2-6, Test Fc: Vibration (sinusoidal), 20m/s² (2.0g)Sinusoidal vibration test IAW MIL-STD-167-1A Shock IEC 60068-2-7, Test Ea: Shock, 20gMedium weight Hammer Shock IAW MIL-S-901D Dimensions(W x H x D) Without illuminator accessory or sunshield: Upright, Inverted:217.75 mm x 368.89 mm x 178.33 mm(8.57 in. x 14.52 in. x 7.02 in.) Canted:217.75 mm x 330.96 mm x 239.68 mm(8.57 in. x 13.03 in. x 9.44 in.) Without illuminator accessory, but with sunshield: Upright, Inverted: 217.75 mm x 372.20 mm x 178.33 mm(8.57 in. x 14.65 in. x 7.02 in.) Canted: 217.75 mm x 334.27 mm x 239.68 mm(8.57 in. x 13.16 in. x 9.44 in.) With illuminator accessory: Upright, Inverted: 217.75 mm x 439.91 mm x 178.33 mm(8.57 in. x 17.32 in. x 7.02 in.) Canted: 217.75 mm x 401.98 mm x 239.68 mm(8.57 in. x 15.83 in. x 9.44 in.) Weight 6.7 kg (14.7 lb) Window Tempered flat glass Construction Material Cast solid aluminum Window Wiper Standard, long-life silicone wiper Sunshield(to prevent sun load in hot climates) Optional; sold separately Canting On-site canting functionality Images
Features
- Certificates (2)
Title Type Language Declaration of Conformity PDF UL PDF - Documents (29)
Title Type Language Data Sheet (MIC IP dynamic 7000 HD) PDF Quick Installation Guide (MIC7000 Camera) PDF Installation Manual PDF Operation Manual (MIC7000 Camera) PDF Addendum (Operation Manual (Canting)) PDF Addendum (User Commands Table for AUTODOME7000, MIC7000) PDF Technical Service Note (- Back-driving MIC cameras) PDF Quick Selection Guide (- MIC Accessories) PDF A/E Specification (MIC IP dynamic 7000 HD) DOCX Special (Product Tests Report - MIC IP dynamic 7000 HD) PDF Release Note (CPP4 H.264 Firmware 6.61.0025) PDF Release Note (CPP4 H.264 Firmware 7.10.0076) PDF Release Note (Video Client 1.7.6 SR3) PDF Release Note (MPEG ActiveX 6.02.0221) PDF CAD Drawing DXF (MIC7000/MIC7000i with illuminator) ZIP CAD Drawing DXF (MIC7000/MIC7000i without illuminator) ZIP CAD Drawing DWG (MIC7000/MIC7000i with illuminator) ZIP CAD Drawing DWG (MIC7000/MIC7000i without illuminator) ZIP CAD Drawing DXF (MIC Mounting Accessories) ZIP CAD Drawing DWG (MIC Mounting Accessories) ZIP Special (- 3D JT file) ZIP Commercial Brochure (IP product overview) PDF Commercial Brochure (MIC IP 7000 HD leaflet) PDF Application note (MIC IP 7000 HD analog integration) PDF Configuration Manual (OSRD Protocol) PDF Special (Bosch IP Video and Data Security Guidebook) PDF WhitePaper (Technical Note: Network Authentication 802.1X) PDF Special (Alarm task script language 7.52) PDF Application note (Outdoor installations) PDF - Software Downloads (4)
Title Type Language CPP4 H.264 Firmware 6.61.0025 ZIP CPP4 H.264 Firmware 7.10.0076 ZIP Video Client 1.7.6 SR3 ZIP MPEG ActiveX 6.02.0221 ZIP
Product variants
MIC-7230-PB4 Ruggedized HD CameraRuggedized 1080p25/30 HD PTZ day/night camera with 30x zoom, high dynamic range; PoE; IVA. Easy install with hinged DCA mount (sold separately). Optional illuminator (sold separately).
Black (RAL 9005). Sand finish.
Commercial Type No.: MIC-7230-PB4
Product No.: F.01U.286.230
MIC-7230-PW4 Ruggedized HD CameraRuggedized 1080p25/30 HD PTZ day/night camera with 30x zoom, high dynamic range; PoE; IVA. Easy install with hinged DCA mount (sold separately). Optional illuminator (sold separately).
White (RAL 9010). Sand finish.
This lens is new enough tech that it does communicate focusing distance with the camera/flash system as designated by the 'D'. 60mm is just too short for serious macro, blocking light on the subject. Also an adapter is required to mount the R1 or R1C1 macro flash system. There are the usual caveats with an older tech lens: the auto focus is slower, noisier, requires a body with a focus motor, and the user must switch between manual and auto focus rather than just over ride.
There are better choices for close macro work, such as the 105mm.
Commercial Type No.: MIC-7230-PW4
Product No.: F.01U.286.231
MIC-7230-PG4 Ruggedized HD CameraRuggedized 1080p25/30 HD PTZ day/night camera with 30x zoom, high dynamic range; PoE; IVA. Easy install with hinged DCA mount (sold separately). Optional illuminator (sold separately).
Grey (RAL 7001). Available in specific regions only. Sand finish.
Commercial Type No.: MIC-7230-PG4
Product No.: F.01U.286.232
Accessories
MIC-ILB-100 MIC7000 ILLUM IR-WT COMBO, BLACK
IR/White light combination illuminator accessory for MIC7000 Series. Field-installable on camera. Detection of moving objects up to 300 m (984 ft) using IR illumination (with MIC-7230 starlight models). 850 nm.
Black (RAL 9005). Sand finish.
Commercial Type No.: MIC-ILB-100
Product No.: F.01U.286.236
MIC-ILW-100 MIC7000 ILLUM IR-WT COMBO, WHITE
White (RAL 9010). Sand finish.
Commercial Type No.: MIC-ILW-100
Product No.: F.01U.286.237
MIC-ILG-100 MIC7000 ILLUM IR-WT COMBO, GREY
Bosch Vg5 7230 Cpt5
Grey (RAL 7001). Available in specific regions only. Sand finish.
Commercial Type No.: MIC-ILG-100
Product No.: F.01U.286.238
High PoE Midspan, 95 W, single port, AC in
High PoE, 95 W, Single Port Midspan with AC in
Commercial Type No.: NPD-9501A
Product No.: F.01U.286.250
High PoE Midspan, 60 W, single port, AC in
High Power, 60 W Single Port PoE Midspan with AC in
Commercial Type No.: NPD-6001A
Product No.: F.01U.275.994
VG4-A-PSU1 120 VAC Power Supply Unit
Power supply with transformer, 120 VAC input, for an AUTODOME or MIC7000 Series PTZ camera. White, aluminum enclosure with cover, rated IP66 and IK 08. 100 W output. Optional trim skirt (sold separately).
Commercial Type No.: VG4-A-PSU1
Product No.: F.01U.261.377
VG4-A-PSU2 230 VAC Power Supply Unit
Power supply with transformer, 230 VAC input, for an AUTODOME or MIC7000 Series PTZ camera. White, aluminum enclosure with cover, rated IP66 and IK 08. 100 W output. Optional trim skirt (sold separately).
Commercial Type No.: VG4-A-PSU2
Product No.: F.01U.261.378
VIDEOJET connect 7000
95 W, PoE IP power supply unit, 100 VAC - 240 VAC (90 VAC - 264 VAC with tolerance considered), 50/60 Hz
Commercial Type No.: VJC-7000-90
Product No.: F.01U.286.249
MIC7000 Alarm/Washer Interface Unit
Interface box for alarms and washer pump connections for MIC7000 cameras, 24 VAC. Impact-resistant polycarbonate enclosure, rated to IP67 and NEMA 4X, with four (4) watertight glands. Grey (RAL 7035).
Commercial Type No.: MIC-ALM-WAS-24
Product No.: F.01U.286.248
MIC-DCA-HB MIC Hinged DCA, Black
DCA mount for a MIC7000 camera. Hinge allows camera to hang temporarily during installation for easier connection of cables/wiring. Aluminum. Two M25 holes for conduit/cable glands.
Black (RAL 9005). Sand finish.
Commercial Type No.: MIC-DCA-HB
Product No.: F.01U.286.244
MIC-DCA-HBA MIC Hinged DCA with Adapter, Black
DCA mount for a MIC7000 camera. Hinge allows camera to hang temporarily during installation for easier connection of cables/wiring. Aluminum. Two M25 holes for conduit/cable glands. Includes an conduit adapter (male M25 to female 3/4' NPT). Available in specific regions only.
Black (RAL 9005). Sand finish.
Brother Installer For Drivers Utilities And User Manual Mac For the latest drivers and utilities we recommend using the 'Go' links in the chart The latest Brother original Printer Driver for OS X v10.10.x is available from the ControlCenter software for easy to use one button scanning from your Mac. Brother Printer Drivers Download Utility is the. Brother Gearmotor delivers the ultimate peace-of-mind by offering an industry leading warranty: a full five years on our entire line of standard products. Download software, drivers, or utilities. If you agree to the terms of the 'End-User License Agreement'. Windows 10 Compatibility If you upgrade from Windows 7 or Windows 8.1 to Windows 10, some features of the installed drivers and software may not work correctly. Brother installer for drivers utilities and user's manual. Step 1: Select the category of your product. Inkjet Printer / Fax / MFC / DCP; Monochrome Laser Printer; Color Printer (Laser / LED) Monochrome Laser Fax / MFC / DCP. This download only includes the printer drivers and is for users who are familiar with installation using the Add Printer Wizard in Windows®. To get the most functionality out of your Brother machine, we recommend you install Full Driver & Software Package. (. Not available for Windows Server®.).
Commercial Type No.: MIC-DCA-HBA
Product No.: F.01U.303.166
MIC-DCA-HW MIC Hinged DCA, White
DCA mount for a MIC7000 camera. Hinge allows camera to hang temporarily during installation for easier connection of cables/wiring. Aluminum. Two M25 holes for conduit/cable glands.
White (RAL 9010). Sand finish.
Commercial Type No.: MIC-DCA-HW
Product No.: F.01U.286.245
MIC-DCA-HWA MIC Hinged DCA with Adapter, White
DCA mount for a MIC7000 camera. Hinge allows camera to hang temporarily during installation for easier connection of cables/wiring. Aluminum. Two M25 holes for conduit/cable glands. Includes an conduit adapter (male M25 to female 3/4' NPT). Available in specific regions only.
White (RAL 9010). Sand finish.
Commercial Type No.: MIC-DCA-HWA
Product No.: F.01U.303.167
MIC-DCA-HG MIC Hinged DCA, Grey
DCA mount for a MIC7000 camera. Hinge allows camera to hang temporarily during installation for easier connection of cables/wiring. Aluminum. Two M25 holes for conduit/cable glands.
Grey (RAL 7001). Available in specific regions only. Sand finish.
Commercial Type No.: MIC-DCA-HG
Product No.: F.01U.286.246
MIC-DCA-HGA MIC Hinged DCA with Adapter, Grey
DCA mount for a MIC7000 camera. Hinge allows camera to hang temporarily during installation for easier connection of cables/wiring. Aluminum. Two M25 holes for conduit/cable glands. Includes an conduit adapter (male M25 to female 3/4' NPT). Available in specific regions only.
Grey (RAL 7001). Sand finish.
Commercial Type No.: MIC-DCA-HGA
Product No.: F.01U.303.168
MIC-WMB-BD Wall Mount Bracket, Black
Wall mount bracket, black sand finish (RAL9005)
Commercial Type No.: MIC-WMB-BD
Product No.: F.01U.143.155
MIC-WMB-WD Wall Mount Bracket, White
Wall mount bracket, white sand finish (RAL9010)
Commercial Type No.: MIC-WMB-WD
Product No.: F.01U.143.156
MIC-WMB-MG Wall Mount Bracket, Grey
Wall Mount Bracket.
Grey (RAL 7001). Available in specific regions only. Sand finish.
Commercial Type No.: MIC-WMB-MG
Product No.: F.01U.296.299
MIC-PMB Pole Mount Bracket
Pole mount bracket (includes 2 x 455 mm stainless steel banding straps for pole diameters 75 to 145 mm)
Commercial Type No.: MIC-PMB
Product No.: F.01U.087.283
MIC-CMB-BD Corner Mount Bracket, Black
Corner mount bracket, black sand finish (RAL9005)
Commercial Type No.: MIC-CMB-BD
Product No.: F.01U.143.158
MIC-CMB-WD Corner Mount Bracket, White
Corner mount bracket, white sand finish (RAL9010)
Commercial Type No.: MIC-CMB-WD
Product No.: F.01U.143.159
MIC-CMB-MG Corner Mount Bracket, Grey
Corner mount bracket.
Grey (RAL 7001). Available in specific regions only. Sand finish.
Commercial Type No.: MIC-CMB_MG
Product No.: F.01U.296.296
MIC-SPR-BD Spreader Plate, Black
Aluminum spreader plate suitable for brickwork surface mounting, black sand finish (RAL9005)
Commercial Type No.: MIC-SPR-BD
Product No.: F.01U.143.164
MIC-SPR-WD Spreader Plate, White
Aluminum spreader plate suitable for brickwork surface mounting, white sand finish (RAL9010)
Commercial Type No.: MIC-SPR-WD
Product No.: F.01U.143.163
MIC-SPR-MG Spreader Plate, Grey
Aluminum spreader plate suitable for brickwork surface mounting.
Grey (RAL 7001). Available in specific regions only. Sand finish.
Commercial Type No.: MIC-SPR-MG
Product No.: F.01U.296.298
MIC-SCA-BD Shallow Conduit Adapter, Black
Shallow conduit adapter for a MIC-WMB, a MIC-PMB, or a MIC-SPR, black sand finish (RAL9005)
Commercial Type No.: MIC-SCA-BD
Product No.: F.01U.143.153
MIC-SCA-WD Shallow Conduit Adapter, White
Shallow conduit adapter for a MIC-WMB, a MIC-PMB, or a MIC-SPR mount, white sand finish (RAL9010)
Commercial Type No.: MIC-SCA-WD
Product No.: F.01U.143.154
MIC-SCA-MG Shallow Conduit Adapter, Grey
Shallow conduit adapter for a MIC-WMB, a MIC-PMB, or a MIC-SPR.
Grey (RAL 7001). Available in specific regions only. Sand finish.
Commercial Type No.: MIC-SCA-MG
Product No.: F.01U.296.297
MIC-67SUNSHLD
Three-part molded sunshield for MIC7000 cameras – 1 bottom shell, 2 top shells (1 for around the optional illuminator accessory). White.
Commercial Type No.: MIC-67SUNSHLD
Product No.: F.01U.286.251
MIC7000 IP67 Connector Kit, 5Pack
Commercial Type No.: MIC-IP67-5PK
Product No.: F.01U.294.750
MIC-WKT-IR Washer Kit
Bosch Vg5-7230-epc5
Washer kit for analog infrared MIC camera models and for MIC7000 camera models only. Includes washer nozzle and mounting brackets for wall or 101.6 mm (4 in.) PCD base. Requires washer pump, purchase separately.
